If the server is in rack mode, remove the server from the rack .
5. Remove the access panel:
a. Loosen the access panel thumbscrew (callout 1).
b. Slide the access panel toward the rear panel, and then lift it away from the chassis (callout 2).
Remove the air baffleRemove the air baffle
CAUTION: CAUTION: For proper cooling, do not operate the server without the access panel, baffles, expansion slot covers, or
blanks installed.
ProcedureProcedure
1. Power down the server.
