10. Remove the M.2 NVMe SSDs from the boot device.
Retain these SSDs for installation onto the new boot device.
To replace the component, reverse the removal procedure.
Removing and replacing a Removing and replacing a boot deviceboot device drive drive
The boot device supports two physical drive sizes:
22110 (110 mm)
2280 (80 mm)
Two drives of the same physical size, or one of each size, can be installed at the same time. Depending on the replacement drive size,
you might need to relocate the M.2 drive retaining latches on the boot device.
CAUTION:CAUTION:
The boot device and the drives installed on the boot device are not hot-pluggable. To remove the boot device, or a
drive from the boot device, you must first power down the server.
CAUTION:CAUTION:
A discharge of static electricity from a finger or other conductor might damage system boards or other static-sensitive
devices. To prevent damage, observe antistatic precautions.
