7. If installed, remove the air baffle .
8. Press and hold the latch (callout 1), and then pull out the blank from the bay (callout 2).
Retain the blank for future use.
9. Install the RDX docking station screws.
These screws are included in the RDX docking station option kit. If the option kit does not include screws, use the media device
screws on the front panel.
10. Slide the RDX docking station into the media bay.
Leave enough space on the rear to connect the USB and power cables.
11. Connect the power and USB cables .
12. Slide the RDX docking station into the media bay until it clicks into place.
13. If removed, install the air baffle .
