HP ProLiant ML30 Gen10 Plus - Storage Controller Backup Power Cabling

Storage controller backup power cablingStorage controller backup power cabling
The exact route of the storage controller backup power cabling will depend on:
The expansion slot where the controller is installed
The location of the storage controller backup power connector on the controller
Use the following diagram for reference only.
Storage controller backup power cabling 181
