HPEHPE NS204i-p NVMe OS Boot Device NS204i-p NVMe OS Boot Device LED definitions LED definitions

ItemItem DescriptionDescription Fault LED statusFault LED status

1 Bay 1 LED Off: Normal

Flashing 1Hz: Drive predictive failure

Amber: Drive failure

2 Bay 2 LED
