10. Remove the blank opposite the selected expansion slot.
Retain the blank for future use.
11. Install the expansion card.
Make sure that the card is seated firmly in the slot.
12. Connect all necessary internal cabling to the expansion card.
For more information on these cabling requirements, see the documentation that ships with the option.
13. Install the PCI blank retainer .
14. If removed, install the air baffle .
15. Install the access panel .
16. Do one of the following:
Orient the server back in tower mode.
