Install the server into the rack .
22. Connect all peripheral cables to the server.
23. Connect each power cord to the server.
24. Connect each power cord to the power source.
25. Power up the server .
Enabling the iLO dedicated network portEnabling the iLO dedicated network port
26. IMPORTANT:IMPORTANT:
If the iLO configuration settings are reset to the default values, remote access to the machine will be lost. Access
the physical machine and repeat the procedure described in this section to re-enable the dedicated iLO
management port.
The onboard NIC 1/iLO shared port is the default system iLO port. Enable the iLO port on the iLO-M.2-serial module
a. From the boot screen, press F9F9 to access the UEFI System Utilities.
b. From the System Utilities screen, select System Configuration > iLO 5 Configuration Utility > Network Options.
c. Set the Network Interface Adapter field to ON, and then press EnterEnter.
d. Press F10F10 to save your changes.
e. Press Enter Enter to reboot the iLO settings.
f. Press Esc Esc until the main menu is displayed.
g. Select Reboot the System to exit the utility and resume the boot process.
The IP address of the dedicated iLO management port appears on the POST screen on the subsequent boot-up. Access the
Network Options screen again to view this IP address for later reference.
Configuring the serial portConfiguring the serial port
27. To configure the serial port setting:
a. From the boot screen, press F9F9 to access the UEFI System Utilities.
b. From the System Utilities screen, select System Configuration > BIOS/Platform Configuration (RBSU) > System Options > Serial
Port Options > Embedded Serial Port.
c. Select a setting.
