3 P4 Connects to the LTO/RDX power extension cable
4 LTO PWR LTO/RDX power connector
5 P2 Connects to the LTO/RDX power extension cable
6 NHP PWR Connects to the SATA-power splitter cable in the 4
LFF non-hot-plug drive configuration
7 BP HP PWR Connects to the 4 LFF / 8 SFF hot-plug drive
backplane
ItemItem Cable labelCable label ConnectionConnection
