Operations 27
Remove the center wall
1. Power down the server (on page 20).
2. Extend or remove the server from the rack ("Extend the server from the rack" on page 22).
3. Remove the access panel. ("Remove the access panel" on page 25)
4. Remove the processor air baffle (on page 26).
5. Remove the full-length expansion boards ("Removing expansion boards" on page 62).
6. Lift the center wall retaining latch.
7. Remove the center wall.
