Cabling 72
Cabling
In this section
Storage device cabling guidelines............................................................................................................ 72
Cable connector identification ................................................................................................................. 72
SAS cabling .......................................................................................................................................... 73
CD-ROM drive cabling ........................................................................................................................... 74
Video cabling........................................................................................................................................ 75
Parallel/serial port cabling...................................................................................................................... 75
Diskette drive cabling ............................................................................................................................. 76
BBWC option cabling............................................................................................................................. 76
Internal USB connector............................................................................................................................ 77
Storage device cabling guidelines
CAUTION: To prevent damage to the equipment, be sure that the server is powered down, all cables are
disconnected from the back of the server, and the power cord is disconnected from the grounded (earthed)
AC outlet before installing devices.
CAUTION: To prevent damage to electrical components, properly ground the server before beginning any
installation procedure. Improper grounding can cause electrostatic discharge.
Cable connector identification
Item Description
1 Power connector
