Installation 11
Installation
In this section
Precautions............................................................................................................................................ 11
Preparing to install the hardware ............................................................................................................. 11
Installing the mounting rails ..................................................................................................................... 13
Preparing the rails for integrated shipping................................................................................................. 15
Installing the UPS ................................................................................................................................... 15
Installing the ERM................................................................................................................................... 23
Precautions
Save these instructions. This document contains important safety instructions that should be followed
during installation, operation, and maintenance of the UPS and batteries.
WARNING: A risk of personal injury from electric shock and hazardous energy levels
exists. The installation of options and routine maintenance and service of this product
must be performed by individuals who are knowledgeable about the procedures,
precautions, and hazards associated with AC power products.
68 kg
150 lb
This symbol indicates that the UPS exceeds the recommended weight for one
individual to handle safely.
WARNING: To reduce the risk of personal injury or damage to the equipment,
observe local occupational health and safety requirements and guidelines for manual
material handling.
75 kg
167 lb
This symbol indicates that the ERM exceeds the recommended weight for one
individual to handle safely.
WARNING: To reduce the risk of personal injury or damage to the equipment,
observe local occupational health and safety requirements and guidelines for manual
material handling.
WARNING: To prevent personal injury from earth conductor leakage current:
• Do not operate the UPS while disconnected from the utility power source.
• Disconnect load devices before disconnecting the UPS from the utility power source.
Preparing to install the hardware
Before installing the hardware:
1. Be sure the necessary tools and materials (on page 12) are available.
2. Select an installation site ("Selecting a site" on page 12).
3. Prepare the equipment ("Readying the equipment" on page 12) for installation in the rack.
