Specifications 44
UPS model
Utility voltage
frequency (Hz)
Available settings utility
voltage (VAC)
Dedicated
branch circuit
rating (A)
Line cord
R5500 XR INTL 50/60
200/208, 220, 230*,
240
32
Nondetachable power
cord with 32 A IEC-309
plug
UPS output specifications
UPS model
Load
segment
Circuit
breaker
Output receptacles Maximum current
R5500 XR NA/JPN 1 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
2 x IEC-320-C13 10 A per receptacle
1 x L6-30R Up to full UPS power rating
2 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
2 x IEC-320-C13 10 A per receptacle
R5500 XR INTL 1 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
2 x IEC-320-C13 10 A per receptacle
1 x IEC-309-32A Up to full UPS power rating
2 15 A¹ 2 x IEC-320-C19 15 A per receptacle²
2 x IEC-320-C13 10 A per receptacle
¹ NOTE: The circuit breakers protect the C19 and C13 outlets.
²
NOTE: If an extension bar is connected to a C19 receptacle, the maximum current for each C13 receptacle
on the extension bar is 10 A. The total maximum current for the extension bar is 12 A.
Power protection specifications
UPS model VA
Nominal power
rating (W)
Nominal voltage
setting
R5500 XR NA/JPN 5000 4500
200/208, 220,
230, 240
R5500 XR INTL 6000 5400 220, 230, 240
5000 4500 200/208
Voltage specifications
Configuration setting (VAC) Available nominal output voltage (VAC)
200/208 204
220 220
230 230
240 240
