Hood Sensor
Description Spare part number
Hood sensor 702772-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 46).
2. Remove the rear I/O panel (
Rear I/O Panel on page 49).
3. Remove the mounting bracket cover (
Mounting Bracket Cover on page 53).
4. Remove the display head back panel (
Display Head Back Panel on page 54).
5. Remove the display head from the stand (
Removing the Display Head from the Stand
on page 90).
6. Remove the rear metal cover (
Rear Metal Plate (EMI shield) on page 91).
7. Disconnect the cable from the system board connector labeled HSENSE (1).
8. Remove the cable from the clip on top of the serial port board (2).
104 Chapter 8 Removal and Replacement Procedures
