Cable Management
Proper routing of the internal cables is critical to the operation of the computer. Follow good cable
management practices when working inside the computer.
●
Keep cables away from major heat sources like the heat sink.
●
Do not jam cables on top of expansion cards or memory modules. Printed circuit cards like these
are not designed to take excessive pressure on them.
●
Do not bend any cable sharply. A sharp bend can break the internal wires.
●
Never bend a SATA data cable tighter than a 30 mm (1.18 in) radius.
●
Never crease a SATA data cable.
CAUTION: When disconnecting cables, always pull the connector - NEVER pull on the cable.
Pulling on the cable could damage the cable.
System board connectors are color-coded to make it easier to find the proper connection.
Cable PCA Designator
Hard drive data SATA0 (Dark Blue)
Hard drive power SATA PWR0
Secondary hard drive data SATA1 (Light Blue)
Fan CPUFAN
LED Hard drive LED
Hood sensor HSENSE
Speaker SPKR
USB+PWR 24V and Cash Drawer port daughter card F13:4A/30V
Display P181
Cable Management 81
