StoreOnce 3500 Series
Storage expansion
The StoreOnce 3500 Series does not support the addition of storage expansion enclosures. It
is supplied with 12 disks installed.
• The StoreOnce 3540 model is supplied with twelve 4–TB disks installed.
• The StoreOnce 3520 model is supplied with twelve 2–TB disks installed.
The base configuration for both models uses 50% of the available capacity (24 TB or 12 TB). If
configured in the factory for the full capacity of 48 TB (3540 model) or 24 TB (3520 model), all
storage will already be licensed. If not factory configured, the license entitlement will be delivered
to the user via email.
IMPORTANT: When increasing storage capacity from 50% to 100%, the only installation and
configuration task is to apply the license for the additional capacity, as described in (page 25).
Optional hardware
The StoreOnce 3500 Series provides four PCIe slots for the addition of StoreOnce 10 GbE or
10 GbE-T Network Cards or StoreOnce 8Gb Fibre Channel cards. These additional PCIe cards
may be pre-installed or supplied in separate boxes. Some cards also require SFP+ transceivers,
which will be supplied with the kit.
IMPORTANT: Refer to the StoreOnce 10 GbE Network Card and StoreOnce Fibre Channel
Card Installation and Configuration Guide for detailed instructions about installing and cabling
optional PCIe cards and make sure the correct SFP+ transceivers are fitted, if required.
Front and rear views
Figure 13 StoreOnce 3500 Series front view
Health LED2NIC status LED1
UID button LED4Power on/standby button and system power LED3
56 Hardware overview reference section
