17 Optional PCIe cards
StoreOnce software version 3.14.0 and later supports the addition of 10 GbE Network and/or
Fibre Channel PCIe cards as listed in the table below.
Table 14 PCIe slot configuration options for StoreOnce Systems
Card choices
PCIe slots available for additional
cardsProduct Name
The addition of 10 GbE and/or FC
cards is not supported
NoneStoreOnce 3100 System
10 GbE SFP or 10 GbE-T Network
card
Four: slots 1, 4, 5 and 6StoreOnce 3500 Series
8 Gb Fibre Channel card
10 GbE SFP or 10 GbE-T Network
card
Four: slots 1, 4, 5 and 6StoreOnce 5100 System
8 Gb Fibre Channel card
10 GbE SFP or 10 GbE-T Network
card
Four: slots 1, 4, 5 and 6StoreOnce 5500 System
8 Gb or 16 Gb Fibre Channel card
PCIe slot allocation at delivery
If you have ordered additional PCIe cards with the base product, the StoreOnce System will have
the correct cards installed in the correct PCIe slots, and they will be configured and licensed
when the product is supplied. You must insert the SFP transceivers, if required, attach the
appropriate cables and connect to the network or FC SAN.
IMPORTANT: For detailed information about installing additional PCIe cards after initial delivery,
see the StoreOnce Optional Hardware Installation and Configuration Guide.
The following drawing illustrates the rear view of a StoreOnce 3500 or 5100 System. Remember
that:
• The cards installed in each slot are determined by your purchase order, so any illustrations
are examples only.
• The PCIe cards must be installed in the correct slot sequence.
For connection to Ethernet, the 10 GbE network cards must be installed, starting with
slot 1, in the slot sequence 1, 4, 5, 6.
◦
◦ For connection to SAN, the FC cards must be installed, starting with slot 6, in the slot
sequence 6, 5, 4, 1.
• SFP+ transceivers are required with the FC cards and the 10 GbE SFP cards. No additional
hardware is required for the 10 GbE Base-T cards.
NOTE: The StoreOnce 3100 System does not support the addition of PCIe cards.
60 Optional PCIe cards
