HP StoreOnce 4900 Backup User Manual

HP StoreOnce 4900 Backup
Table 3 HP StoreOnce 4900 models
Storage expansionPortsInterfaces supportedDescriptionProduct model
4 x 1GbE ports 4 x
10GbE ports4 x FC
ports
iSCSI and FCA head server unit
with two 1TB disks
and a pre-configured
HP StoreOnce 4900
48TB Backup,
BB903A
1. Up to five 11–disk
expansion kits for
the first disk
two-drawer disk enclosure,
BB908A2.enclosure with eleven
4TB disks and four hot
spare disks
2. When the first
enclosure is full,
one additional disk
11–disk expansion kitBB908A
enclosure with
11+4 spare
One additional disk
enclosure with 11+4
BB904A
pre-configured
storage, BB904A.
spare pre-configured
storage
This can also be
expanded with up
to five 11–disk
expansion kits,
BB908A.
Front view of the HP StoreOnce 4900 Backup
Figure 1 Front view of the HP StoreOnce 4900 Backup
Disk enclosure2.Head server1.
Drawer 2 (right-hand side of enclosure)4.1U support shelf3.
Drawer 1 (left-hand side of enclosure)5.
WARNING! If a second disk enclosure is to be installed, HP recommends installing the second
disk enclosure below the head server unit. If the second disk enclosure is installed above the head
server unit, the 1U support shelf supplied with the disk enclosure should be installed immediately
above the head server unit to protect it from the weight of the disk enclosure
16 Before you start
