7. Flex the front of the right side rail, and then withdraw the front pin from the hard drive by gently
pulling the side rail down and away.
8. Remove the drive from the hard drive tray.
9. Fold up the flap near the back of the hard drive tray.
Note
Folding up the flap improves air flow and helps keep the server cool.
10. With the handle up, slide the hard-drive tray back into the system bay.
11. Close the handle on the hard drive tray until it locks.
12. Close the door on the front of the server.
223
