HP Data Vault User's Guide

Hardware Status Levels

Green Yellow Red

Fan Speed

Greater than or equal to

800 rpm

Between 600 rmp and

800 rpm

Less than 600 rpm

Temperature (PECI)

Less than 85 Between 85 and 100 Greater than or equal to

100

3.3V

Between 3.069V and

3.531V

7-10% greater or lesser

than 3.3V

More than 10% greater

or lesser than 3.3V

5.0V

Between 4.650V and

5.350V

7-10% greater or lesser

than 5.0V

More than 10% greater

or lesser than 5.0V

12.0V

Between 10.200V and

13.800V

15-20% greater or

lesser than12.0V

More than 20% greater

or lesser than 12.0V

5. Click OK.
