Specifications13
This section provides specifications for your computer.
Table 13-1 Specifications
Metric U.S.
Dimensions
Height 216 mm 8.5 in
Width 551 mm 21.7 in
Depth 445 mm 17.5 in
Approximate weight 31.7 kg maximum, 22.4 kg
minimum, 23.7 kg typical
(exact weights depend
on configuration)
70.0 lbs maximum,
49.4 lbs minimum,
52.2 lbs typical (exact
weights depend on
configuration)
Temperature range
Operating 5°C to 35°C 40°C to 95°F
Nonoperating –40°F to 60°C –40°F to 140°F
NOTE: Operating temperature is derated 1.0°C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level; no direct sustained
sunlight. Maximum rate of change is 10° C/Hr. The upper limit might be limited by the type and number of options installed.
Maximum altitude (unpressurized)
Operating (with solid-state drives) 5,000 m 16,404 ft
Operating (with hard drives) 3,048 m 10,000 ft
Nonoperating 15,240 m 50,000 ft
Relative humidity (noncondensing)
Operating 10% to 90% 10% to 90%
Nonoperating (38.7°C max wet bulb) 5% to 95% 5% to 95%
Power supply
Operating voltage range 90 V ac to 269 V ac
Rated voltage frequency range 100-127 V ac @ 50-60 Hz, 200-240 V ac @ 50-60 Hz,
118 V ac @ 400 Hz
Operating line frequency range 100-127 V ac @ 47-66 Hz, 200-240 V ac @ 47-66 Hz,
118 V ac @ 393-407 Hz
Rated input current 12A @ 100-127 V ac, 10A @ 200-240 V ac, 12A @ 118 V
ac
Efficiency 87/90/87% efficient at 20/50/100% load (@ 115 V)
104 Chapter 13 Specifications
