4. Disconnect the memory fan cable (4) from the system board.
5. Remove the memory fan.
To install the memory fan, reverse the removal procedure.
Rear fan
To remove the rear fan, use these procedures.
Before removing the rear fan, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 18).
2. Remove the access panel (see Access panel on page 20).
Remove the rear fan:
1. Remove the four Phillips M5.0 × 12.0 screws (1) that secure the rear fan to the computer.
2. Lift the rear fan (2) as far as the rear fan cable allows.
28
Chapter 4 Removal and replacement procedures
