HP Z Series

Illustrated parts catalog2
Use this information to determine the spare parts that are available for the computer.
NOTE: HP continually improves and changes product parts. For complete and current information
about supported parts for your computer, go to http://partsurfer.hp.com, select your country or region,
and then follow the on-screen instructions.
Computer major components
To identify the computer major components, use this illustration and table.
Table 2-1
Computer major components and their descriptions
Item Description
(1) Heat sink
(2) Processor
(3) Memory modules (4)
(4) Access panel
(5) PCIe card
(6) Rear fan
(7) Memory fan
(8) System board
(9) Front card guide and fan
(10) Memory fan duct
(11) Chassis
6 Chapter 2 Illustrated parts catalog
