133
− Set the IP address to 192.168.0.112.
− Set the accounting port number to 1813.
− Set the shared key to radius.
− Set the server state to Active.
e. Configure the switch to not include domain names in the usernames sent to the RADIUS
server.
f. Click the Advanced settings icon on the RADIUS page.
g. Enable the session-control feature.
3. Configure an ISP domain on Switch A:
a. From the navigation tree, select Security > Authentication > ISP Domains.
b. Add ISP domain dm1, and set the domain state to Active.
c. Set the access service to Portal.
d. Configure the ISP domain to use RADIUS scheme rs1 for authentication, authorization, and
accounting of portal users.
e. Click the Advanced settings icon on the ISP Domain page.
f. Specify dm1 as the default ISP domain. If a user enters the username without the ISP
domain name at login, the authentication and accounting methods of the default domain are
used for the user.
4. Configure the VLAN and the VLAN interface on Switch A:
a. From the navigation tree, select Network > Links > VLAN.
b. Create VLAN 4.
c. Open the details page for VLAN 4.
d. Create VLAN-interface 4 and assign IP address 20.20.20.1 to it.
5. Configure portal authentication on Switch A:
a. From the navigation tree, select Security > Access Control > Portal.
b. Add a portal authentication server:
− Specify the server name as newpt.
−
Specify the IP address as 192.168.0.111.
− Specify the shared key as portal.
− Set the server listening port to 50100.
c. Add a portal Web server:
− Specify the server name as newpt.
− Specify the URL.
The URL must be the same as the URL of the portal Web server used in the network.
This example uses http://192.168.0.111:8080/portal.
d. Add an interface policy:
− Select interface VLAN-interface 4.
− In the IPv4 configuration area, enable portal authentication and select the Layer3
method.
− Select portal Web server newpt.
− Configure the BAS-IP address as 20.20.20.1.
6. Configure the RADIUS server:
a. Add a user account on the server. (Details not shown.)
b. Configure the authentication, authorization, and accounting settings. (Details not shown.)
