Operations 34
9.
Power up the server ("Powering up the server" on page 30).
10. Do one of the following:
o For tower models, install the tower bezel (on page 31).
o For rack models, if removed, install the security bezel ("Security bezel option" on page 50).
Extend the server from the rack
WARNING:
To reduce the risk of personal injury or equipment damage, be sure that the rack
is adequately stabilized before extending a component from the rack.
1. Remove the security bezel ("Remove the security bezel (optional)" on page 31).
2. Power down the server (on page 30).
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Loosen the screws from the latch ears and release the latches on each side of the server.
5. Extend the server from the rack.
6. After completing the maintenance procedure, slide the server back into the rack, and then press the
server firmly into the rack to secure it in place.
WARNING: To reduce the risk of personal injury, be careful when pressing the server
rail-release latches and sliding the server into the rack. The sliding rails could pinch your
fingers.
Remove the air baffle
CAUTION: For proper cooling, do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed. If the server supports hot-plug components,
minimize the amount of time the access panel is open.
To remove the component:
1. Do one of the following:
