Item Description Status
Right LED
Link/Activity mode:
• O = No activity
• Flashing green = Activity at 10Gb
PID:
Always o
Ethernet:
Always o
Fibre Channel:
Always o
4
Fibre Channel (FC) mode
LED
Solid green = FC mode is selected.
5 Ethernet mode LED Solid green = Ethernet mode is selected.
6 PID mode LED Solid green = PID mode is selected.
7 Link/Activity mode LED
2
Solid green = Link/Activity mode is selected.
8 Health LED Solid green = Normal
Flashing amber = There is a fault condition
Flashing red = Critical fault detected
Solid red = No power present
9 Mode button
Press and hold the Mode button for more than 5 seconds to reset.
Solid green = There are four LEDs that indicate the operating mode for the
Port LEDs. The operating mode is selected by pressing the Mode button on
the front panel. The LED mode state determines which of the four Mode
LEDs is lit.
10 UID LED Solid blue = Activated
Flashing blue = Firmware upgrade in progress
O = Deactivated
1
See HPE OneView (
http://www.hpe.com/info/oneview/docs)
2
When illuminated, the QSFP28 port LEDs indicate the port operating states for each of the uplink ports in the selected mode.
38 Component and LED identification
