hpmont HD20 Series User Manual

Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD20 Series Inverters User Manual －119－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
d00.11
Master setting frequency
source
0－4 *
d00.12 Master setting frequency 0.01－400.00Hz *
d00.13 Auxiliary setting frequency 0.01－400.00Hz *
d00.14 Setting frequency 0.01－400.00Hz *
d00.15
Reference frequency
(after acceleration/
deceleration)
0.01－400.00Hz *
d00.16 Output frequency 0.01－400.00Hz *
d00.17 Setting speed 0－60000rpm *
d00.18 Running speed 0－60000rpm *
d00.19 Reserved
d00.20 Output voltage 0－999V *
d00.21 Output current 0.1A－999.9A *
d00.22 Reserved
d00.23 Output torque
0－300.0% (motor rated
torque)
*
d00.24 Output power 0－200% (motor rated power) *
d00.25 DC bus voltage 0－999V *
d00.26
Potentiometer input
voltage of the display
panel
0.00－5.00V *
d00.27 AI1 input voltage 0.00－10.00V *
d00.28
AI1 input voltage (after
disposal)
0.00－10.00V *
d00.29 AI2 input voltage -10.00－10.00V *
d00.30
AI2 input voltage (after
disposal)
-10.00－10.00V *
d00.31 Reserved
d00.32 Reserved
d00.33 Reserved
d00.34 Reserved
d00.35
DI6 terminal pulse input
frequency
0－50000Hz *
d00.36 AO1 output 0.00－10.00V *
d00.37 AO2 output 0.00－10.00V *
d00.38
High-speed output pulse
frequency
0－50000Hz
*
d00.39 Heatsink temperature 0.0－999.9℃ *
d00.40 Setting line speed 0－max output line speed *
d00.41 Reference line speed 0－max output line speed *
d00.42 Reserved
A
