hpmont HD20 Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―120― HD20 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
d00.43 Reserved
d00.44 Process PID reference -100.0－100.0% *
d00.45 Process PID feedback -100.0－100.0% *
d00.46 Process PID tolerance -100.0－100.0% *
d00.47 Process PID integral item -100.0－100.0% *
d00.48 Process PID output -100.0－100.0% *
d00.49 External counting value 0－9999 *
d00.50 Input terminal status
Bit0－Bit8 corresponding to
DI1－DI9
Bitx: DIy terminals input
positive and negative logic
0: Positive logic
1: Negative logic
*
d00.51 Output terminal status
Bit0－Bit1 corresponding to
DO1－DO2
Bit2－Bit11 corresponding to
RLY1－RLY10
Bitx: DOy, RLYy terminals
output positive and negative
logic
0: Positive logic
1: Negative logic
*
d00.52
MODBUS communication
status
0: Normal
1: Communication timeout
2: Incorrect data frame head
3: Incorrect data frame
checking
4: Incorrect data frame content
*
d00.53 Actual length 0－65535m *
d00.54 Total length 0－65535km *
d00.55 Total time at power-on (h) 0－65535h *
d00.56 Total time at operation (h) 0－65535h *
d00.57
High bit of motor total
energy consumption
0－65535k kW.h *
d00.58
Low bit of motor total
energy consumption
0.0－999.9kW.h *
d00.59
High bit of energy consum.
at this time running
0－65535k kW.h *
d00.60
Low bit of energy consum.
at this time running
0.0－999.9kW.h *
d00.61 Fault at the moment 1－99 *
Group F00 Basic Parameter (refer to pages 52
－
54)
F00.00 Reserved
F00.01 Control mode selection 0: V/f control without PG 0 1 ×
