Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD20 Series Inverters User Manual -123-
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
EEPROM parameter 2 to the
current function code settings
(including the motor
parameters).
F01.03
Display panel EEPROM
parameter initialization
0: No operation
1: Upload the current function
code settings to the display
panel EEPROM parameter 1
2: Upload the current function
code settings to the display
panel EEPROM parameter 2
0 1 ○
Group F02 Run/Stop Control Parameters (refer to pages 56
59)
F02.00 Start mode selection
0: From the DWELL frequency
to start
1: Brake first and then start
from DWELL frequency
2: Start after speed tracking. If
the result of speed tracking is
smaller than F02.02, it will start
from the starting DWELL
frequency
0 1 ×
F02.01 Starting delay time 0.00-10.00s 0.00s 0.01s ×
F02.02
Start DWELL frequency
setting
0.00-upper limit 0.00Hz 0.01Hz ×
F02.03
Retention time of starting
DWELL frequency
0.00-10.00s 0.00s 0.01s ×
F02.04 DC braking current setting
0-100% (inverter’s rated
current)
50% 1% ×
F02.05 DC braking time at start 0.00-60.00s 0.50s 0.01s ×
F02.06 Reserved
F02.07
Speed search mode
based on current
0: From the max. output
frequency to start speed
searching
1: From at stop moment
frequency to start speed
searching
1 1 ×
F02.08
Setting reference current
for speed search
0-100% (motor’s rated
current)
50% 1% ×
F02.09
Acc./Dec. time of the
speed search
1.0-50.0s 5.0s 0.1s ×
F02.10
Waiting time of speed
search
0.1-5.0s 1.0s 0.1s ×
F02.11 V/f ratio of speed search 0.0-100.0% 100.0% 0.1% ×
F02.12
Disposal time after speed
search
0.01-5.00s 1.00s 0.01s ×
F02.13 Stop mode selection
0: Decelerate to stop
0 1 ×
A
