hpmont HD20 Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―128― HD20 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
command 14
F06.14
Multi-step frequency
command 15
F00.09－upper limit 45.00Hz 0.01Hz ○
F06.15
Simple PLC control
selection
0: No PLC operation
1: Enabling PLC operation
0 1 ×
F06.16
Simple PLC operation
mode selection
Units: PLC operation mode
selection
0: Stop after single cycle
operation
1: Maintain the final value after
single cycle of PLC operation
2: Cycle operation
Tens: PLC operation restart
mode selection after pause
0: Start from step 1
1: Continue to operate from
the step where the inverter
pauses
2: Continue to operate at the
frequency when the inverter
pauses
Hundreds: Save the PLC
status after power failure
0: Not be saved
1: Saved
Thousands: time unit selection
of the PLC step
0: Second (s)
1: Minute (m)
0000 1 ×
F06.17 Setting of PLC step 1
Units: PLC running frequency
selection
0: Multi- step frequency
command
1: Depend on F00.10
Tens: Operation direction
selection of PLC at different
step
0: Forward
1: Reverse
2: Depend on run command
000 1 ○
F06.19 Setting of PLC step 2 000 1 ○
F06.21 Setting of PLC step 3 000 1 ○
F06.23 Setting of PLC step 4 000 1 ○
F06.25 Setting of PLC step 5 000 1 ○
F06.27 Setting of PLC step 6 000 1 ○
F06.29 Setting of PLC step 7 000 1 ○
F06.31 Setting of PLC step 8 000 1 ○
F06.33 Setting of PLC step 9 000 1 ○
F06.35 Setting of PLC step 10 000 1 ○
F06.37 Setting of PLC step 11 000 1 ○
F06.39 Setting of PLC step 12
Hundreds: Acc./Dec. time
000 1 ○
