Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD20 Series Inverters User Manual 141
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F16.20
AO2 terminal output
function selection
5: Output current (0twice
motor’s rated current)
69: Reserved
10: Output torque (03 times
motors rated torque)
11: Output voltage (01.2
times inverters rated voltage)
12: Bus voltage (02.2 times
inverter’s rated voltage)
13: Output power (0twice
motors rated power)
14: AI1 input (010V)
15: AI2 input (-1010V / 0
20mA)
16, 17: Reserved
18: Output frequency (- 1 times
1 times maximum output
frequency)
19: Reference frequency (- 1
times1 times maximum
output frequency)
0 1
F16.21
High-speed pulse output
function selection
0 1
F16.22 Analogue output AO1 bias -100.0100.0% 0.0% 0.1%
F16.23 Analogue output AO1 gain 0.0200.0% 100.0% 0.1%
F16.24 Analogue output AO2 bias -100.0100.0% 0.0% 0.1%
F16.25 Analogue output AO2 gain 0.0200.0% 100.0% 0.1%
F16.26
DO2 maximum output
pulse frequency
0.150.0kHz 10.0kHz 0.1kHz
Group F17 SCI Communication Parameters (refer to pages 92
93)
F17.00 Data format
0: 1-8-2 format, no parity, RTU
1: 1-8-1 format, even
parity,RTU
2: 1-8-1 format, odd parity,
RTU
3: 1-7-2 format, no parity,
ASCII
4: 1-7-1 format, even parity,
ASCII
5: 1-7-1 format, odd parity,
ASCII
0 1 ×
F17.01 Baud rate selection
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
5: 38400bps
3 1 ×
F17.02 Local address 0247 2 1 ×
