hpmont HD20 Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―140― HD20 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F15.41 Reserved
F15.42 Reserved
F15.43 Terminal output delay 0.0－100.0s 0.0s 0.1s ×
Group F16 Analogue I/O Terminal Parameters (refer to pages 88
－
92)
F16.00
Display panel with
potentiometer function
selection
0: Reserved
1: Upper limit frequency setting
2: Frequency setting
3: Auxiliary frequency
reference
4: Process PID reference
5: Process PID feedback
6: Process PID regulating
upper limit
7: Process PID regulating
lower limit
0 1 ×
F16.01
Analogue input AI1
function selection
2 1 ×
F16.02
Analogue input AI2
function selection
5 1 ×
F16.03 Reserved
F16.04 Reserved
F16.05 Analogue input AI1 bias -100.0－100.0% 0.0% 0.1% ○
F16.06 Analogue input AI1 gain -10.00－10.00 1.00 0.01 ○
F16.07
Analogue input AI1
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.08 Analogue input AI2 bias -100.0－100.0% 0.0% 0.1% ○
F16.09 Analogue input AI2 gain -10.00－10.00 1.00 0.01 ○
F16.10
Analogue input AI2
filtering time
0.01－10.00s 0.05s 0.01s ○
F16.11 Reserved
F16.12 Reserved
F16.13 Reserved
F16.14 Reserved
F16.15 Reserved
F16.16 Reserved
F16.17
Maximum input pulse
frequency
0.0－50.0kHz 10.0kHz 0.1kHz ○
F16.18 Input pulse filtering time 0－500ms 10ms 1ms ○
F16.19
AO1 terminal output
function selection
0: Reserved
1: Output frequency (0－max.
output frequency)
2: Reference frquency (0－
max. output frequency)
3: Motor RPM (0－maximum
output frequency
corresponding to speed)
4: Output current (0－twice
motor’s rated current)
1 1 ○
