Chapter 3 Mechanical Installation Shenzhen Hpmont Technology Co., Ltd
―12― HD20 Series Inverters User Manual
Figure 3-1 Parallel installation of the inverter
When one inverter is mounted on the top of the other, an air flow diverting plate should be fixed in
between. Just as shown in Figure 3-2.
Figure 3-2 Installation of several inverters
LOCK
FWD REV ALM
LO/RE
HZ A V RPM
%
LOCK
FWD REV ALM
LO/RE
HZ A V RPM
%
≥ 100mm
≥ 100mm
LOCK
FWD REV ALM
LO/RE
HZ A V RPM
%
LOCK
FWD REV ALM
LO/RE
HZ A V RPM
%
