Connection with peripheral devices
Three-phase AC power supply
Contactor
AC input reactor
EMI filter
EMI filter
HD20 series inverter
AC output reactor
Motor
Ground connection
Ground connection
Braking resistor
(optional)
MCCB
SHF
ENT
PRG
JOG
RUN
STOP
