Page #68 background imageLoading...
Page #68 background image
Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD20 Series Inverters User Manual 53
No. Name Description Range
factory setting
F00.10 Frequency setting sources selection 0
4
0
0: Display panel digital setting. Change the value by pressing the or key of the display panel.
Initial value is set by F00.13.
1: Terminal digital setting. Change the value by using the terminals UP/DN. F00.13 sets initial value.
2: SCI communication setting. Chang the setting frequency by SCI communication frequency
command.
The initial value of the SCI communication frequency is 0.
3: Analogue setting. It is set by the analogue input voltage.
See Group F16.
The corresponding relationship between the analogue value of AI1 and the inverter’s running
frequency setting is refered to Group F05.
4: Terminal pulse setting. It is set by the terminal pulse DI6.
The specification of input pulse signal: voltage range: 1530V; frequency range: 050.0kHz.
Refered to Group F05 for the corresponding relationship between the pulse terminal frequency
and the inverters running frequency setting.
F00.11 Command setting source selection 0
2
0
0: Display panel running source. Start and stop the inveter by pressing the key , , .
1: Terminal running source. Start and stop by using the corresponding external terminals.
External terminal FWD (multi-function terminal is set to 2), REV (multi-function terminal is set to
3), JOGF1 (multi-function terminal is set to 20), JOGR1 (multi-function terminal is set to 21),
JOGF2 (multi-function terminal is set to 22), JOGR2 (multi-function terminal is set to 23). For
more information please see Group F15.
2: SCI communication running source. Start and stop by SCI communication port according to
communication protocol.
F00.12 Function selection of the multi-function key 0
2
2
0: Switch the display panel running direction. Switch the display panel running direction by key.
When F00.11 = 0, it is valid. Do not save when power is off.
1: Switch local and remote control. Switch the local and remote control by ke y.
When F00.11 = 0 or 1, it is valid.
2: The multi-function key is invalid.
F00.13 Starting frequency digital setting 0.00
upper limit
50.00Hz
When F00.10 = 0 or 1, F00.13 start to set the initial frequency value.
F00.14 UP/DOWN digital setting control 0000
1101
1001
Only when F00.11 = 0 or 1 will it be valid.
The current setting frequency value will be replaced by a new one when the value of the F00.13
has be changed by the parameter setting.
Units: Frequency setting save selection at power outage
0: Frequency setting will not be saved at power outage.
1: Frequency setting will be saved to F00.13 at power outage.
Tens: Frequency setting control selection at stop
0: Frequency setting will be the same at stop.
1: Frequency setting will be restored to F00.13 at stop.
RUN
STOP
JOG
6
