4. Start and stop the local address 2 of inverter via SCI communication function code 0x06 writing
register 0x3200, such as forward start command, as following table.
Address Code Register address Register content Checksum
Command
frame
0x02 0x06 0x32 0x00 0x10 0x01 0x4B 0x41
Answer
frame
0x02 0x06 0x32 0x00 0x10 0x01 0x4B 0x41
Deceleration stops command, as following table.
Address Code Register address Register content Checksum
Command
frame
0x02 0x06 0x32 0x00 0x10 0x04 0x8B 0x42
Answer
frame
0x02 0x06 0x32 0x00 0x10 0x04 0x8B 0x42
5. Modify the running frequency via SCI communication function code 0X06 writing register
0x3201. Such as: modify the local address two of slave with running frequency of 45.00Hz, as
following table.
Address Code Register address Register content Checksum
Command
frame
0x02 0x06 0x32 0x01 0x11 0x94 0xDB 0x7E
Answer
frame
0x02 0x06 0x32 0x01 0x11 0x94 0xDB 0x7E
