Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －149－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
1: Enabled
F19.19 Stall overvoltage point 0－999V 700V 1V ×
F19.20
Auto current limiting
selection
0: Disabled
1: Enabled in Acc./Dec.
running process, but
disabled in constant speed
runnng process
2: Enabled both in Acc./Dec.
and in constant speed
running proces
0 1 ×
F19.21
Auto current limiting
threshold
20.0－200.0%
G：150.0%
P：110.0%
0.1% ×
F19.22
Deceleration time at
auto current limiting
0.1－6000.0s 5.0s 0.1s ×
F19.23
Enabled mode of
terminal run command
0: Rise edge enabled mode
1: Level enabled mode
0 1 ○
F19.24
Action voltage of
braking unit
220V: 380－450V
380V: 630－750V
Dependent
on inverter
model
1V ×
F19.25 Reserved
F19.26 Preset length 0－65535m 0m 1m ×
F19.27 Actual length 0－65535m 0m 1m *
F19.28 Length ratio 0.001－30.000 1.000 0.001 ×
F19.29
Length checking
coefficient
0.001－1.000 1.000 0.001 ×
F19.30
Measuring shaft
diameter
1.00－100.00cm 10.00cm 0.01cm ×
F19.31
Number of pulses per
revolution
1－9999 1 1 ×
F19.32
Length arrive and
output function
selection
0: Output level signal
1: Output 500ms pulse
0 1 ○
F19.33
Record of length
disposal after length
arrive
0: Auto-clear
1: No change
0 1 ○
F19.34
Record of length
disposal at stop
0: Auto-clear
1: No change
0 1 ○
F19.35 Reserved
F19.36 Reserved
F19.37 Reserved
F19.38 Reserved
Group F20 Protection of Fault Parameters (refer to pages 105
－
108)
F20.00
Overload pre-alarm
detection
Units: Overload pre-alarm
detection
00000 1 ×
A
