Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―154― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
Group F23 PWM Control Parameters (refer to pages 109
－
109)
F23.00
Set the carrier
frequency
1－16kHz
Dependent
on inverter
model
1kHz ×
F23.01 Reserved
F23.02 PWM overshoot enable
0: Disabled
1: Enabled
1 1 ×
Group U User Menu Mode Display Parameters (refer to parameters 109
－
110)
U00.00
User menu map of
setting 1
00.00－23.02,99.99
99.99 is corresponding to no
parameter mapping function
99.99 0.01 ○
U00.02
User menu map of
setting 2
99.99 0.01 ○
U00.04
User menu map of
setting 3
99.99 0.01 ○
U00.06
User menu map of
setting 4
99.99 0.01 ○
U00.08
User menu map of
setting 5
99.99 0.01 ○
U00.10
User menu map of
setting 6
99.99 0.01 ○
U00.12
User menu map of
setting 7
99.99 0.01 ○
U00.14
User menu map of
setting 8
99.99 0.01 ○
U00.16
User menu map of
setting 9
99.99 0.01 ○
U00.18
User menu map of
setting 10
99.99 0.01 ○
U00.20
User menu map of
setting 11
99.99 0.01 ○
U00.22
User menu map of
setting 12
99.99 0.01 ○
U00.24
User menu map of
setting 13
99.99 0.01 ○
U00.26
User menu map of
setting 14
99.99 0.01 ○
U00.28
User menu map of
setting 15
99.99 0.01 ○
U00.30
User menu map of
setting 16
99.99 0.01 ○
U00.01
The setting value of
map 1
―
― ―
U00.03
The setting value of
map 2
― ―
