Shenzhen Hpmont Technology Co., Ltd Appendix C Communication Protocol
HD30 Series Inverters User Manual －167－
Register
address
Parameter name
Register
address
Parameter name
0x3304 Reversed 0x331E AI2 input voltage (after disposal)
0x3305
Software version of the display
panel
0x331F
AI3 input voltage
0x3306 Custom series No. 0x3320 AI3 input voltage (after disposal)
0x3307
Units: the current motor
0: Motor 1
1: Motor 2
Tens: control mode
0: V/f control without PG
1: Reversed
2: Vector control without PG
0x3321 AI4 input voltage
0x3322 AI4 input voltage (after disposal)
0x3323
DI6 terminal pulse input
frequency
0x3324 AO1 output
0x3325 AO2 output
0x3326
High-speed output pulse
frequency
0x3327 Heatsink temperature
0x3328 Reversed
0x3308 Inverter’s rated current 0x3329 Reversed
0x3309 Inverter’s extension function 0x332A Reversed
0x330A
Units:
Bit0: Inverter fault
Bit1: Run/stop
Bit2: Forward/reverse
Bit3: Zero speed to run
Tens:
Bit0&1: Acc./ Dec./ constant
Bit2: Reversed
Bit3: DC braking (includes
starting DC braking and stop DC
braking)
Hundreds:
Bit0: Parameter auto-tuning
Bit1: Reversed
Bit2: Speed limitation
Bit3: Reversed
Thousands:
Bit0: Stall overvoltage
Bit1: Stall overcurrent
Bit2: Reversed
Bit3: Reversed
0x332B Reversed
0x332C Process PID reference
0x332D Process PID feedback
0x332E Process PID error
0x332F Process PID integral
0x3330 Process PID output
0x3331 External counting value
0x3332 Input terminal status
0x3333 Output terminal status
0x3334 MODBUS communication status
0x3335 Actual length
0x3336 Total length
0x3337 Total time at power on (hour)
0x3338 Total time at running (hour)
0x3339 High byte of motor total energy
0x333A Low byte of motor total energy
0x333B High byte of this running energy
0x333C Low byte of this running energy
0x333D The current fault code
0x333E Reversed
0x330B Master setting frequency source 0x333F Reversed
0x330C Master setting frequency 0x3340 Reversed
0x330D Auxiliary setting frequency 0x3341 Reversed
0x330E Setting frequency 0x3342 Reversed
0x330F Reference frquency (after 0x3343 Reversed
C
