No. Name Description Range
【
factory setting
】
Note: The difference between Mode 1 and Mode 2 is that Mode 2 also memorizes the running
frequency when the inverter pauses, and the inverter will continue to operate at the frequency
upon restart.
Hundreds: Save the PLC status after power failure
• 0: Not save. The PLC running status will not be saved after power failure and start running from
Step 1 next time.
• 1: Save. The operating parameters of PLC operation, including the operating step, operating
frequency and operating time of this step,etc, can be saved. The inverter will continue to operate
in accordance with the PLC operation restart mode selection after pause (tens of F06.16 defines).
Thousands: time unit selection of the PLC step
• 0: Second (s).
• 1: Minute (m).
F06.17
Setting of PLC step 1
000－321【000】
F06.19 Setting of PLC step 2 000
－
321
【
000
】
F06.21
Setting of PLC step 3
000－321【000】
F06.23 Setting of PLC step 4 000
－
321
【
000
】
F06.25
Setting of PLC step 5
000－321【000】
F06.27 Setting of PLC step 6 000
－
321
【
000
】
F06.29
Setting of PLC step 7
000－321【000】
F06.31 Setting of PLC step 8 000
－
321
【
000
】
F06.33
Setting of PLC step 9
000－321【000】
F06.35 Setting of PLC step 10 000
－
321
【
000
】
F06.37
Setting of PLC step 11
000－321【000】
F06.39 Setting of PLC step 12 000
－
321
【
000
】
F06.41
Setting of PLC step 13
000－321【000】
F06.43 Setting of PLC step 14 000
－
321
【
000
】
F06.45
Setting of PLC step 15
000－321【000】
F06.17, F06.19, F06.21, F06.23, F06.25, F06.27, F06.29, F06.31, F06.33, F06.35, F06.37, F06.39,
F06.41, F06.43, F06.45 are used to configure the running frequency, the direction, acceleration and
deceleration time of every PLC step.
Units: PLC running frequency selection
• 0: Multi- step frequency command. The absolute value of each step frequency is the same as the
setting of multi-step frequency.
• Example: the absolute value of running frequency in PLC Step 15 is the setting value of F06.14.
• 1: Depend on F00.10. The running frequency source selectes the reference by F00.10 selection.
Tens: Operation direction selection of PLC at different steps
• 0: Forward.
• 1: Reverse.
• 2: Depend on run command. The motor’s operation direction can be alternated via external
direction command.
• If the direction is not set, the inverter will run in the direction according to last step.
Hundreds: Acceleration/deceleration time selection of PLC at different steps
• 0: Acceleration/deceleration time 1.
• 1: Acceleration/deceleration time 2.
• 2: Acceleration/deceleration time 3.
• 3: Acceleration/deceleration time 4.
