Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―72― HD30 Series Inverters User Manual
No. Name Description Range
factory setting
Hundreds: Restart mode of wobble operation.
• 0: The inverter restarts the wobble operation as per the recorded frequency and direction when it
stops last time.
• 1: The inverter restarts the wobble operation from 0 Hz.
Thousands: Save the wobble operation parameters at power outage
• 0: Saved. When the hundreds of F07.01 is set as 0, the wobble operation parameters will be
saved when power outage occurs.
• 1: Not be saved.
F07.03 Holding time of preset wobble frequency 0.0
999.9s
0.0
F07.02 defines the inverter’s running frequency before entering wobble mode.
F07.03 defines the time that the inverter operates at the preset wobble frequency.
• Only when select auto start (set units of F07.01 as 0) will F07.03 be enabled.
F07.04 Wobble amplitude 0.0
50.0%
0.0
Relative to central frequency: F
W
= central frequency × F07.04.
• Wobble central frequency is the frequency value set by F00.10 (frequency reference source).
Relative to maximum output frequency: F
W
= maximum output frequency F00.06 × F07.04.
F07.05 Jump frequency 0.0%
F07.04
0.0%
The setting is the percentage of wobble amplitude. There is not jump frquency if set as 0.
F07.06 Wobble operation cycle 0.1
999.9s
10.0
F07.06 defines a complete cycle of wobble operation including rising and falling processes.
F07.07 Rising time of triangle wave 0.0
100.0%
50.0
Relative to wobble operation cycle of the F07.06, F07.07 defines the rising and the falling time of
wobble operation and their unit is s.
• Rising time of wobble operation ＝ F07.06 × F07.07.
• Falling time of wobble operation ＝ F07.06 × (1 - F07.07).
