Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
―42― HD3L Series Controller User Manual
6.1 Group d: Display parameter
Group D is status display parameters.
6.1.1 d00: Status Display Parameters
Ref. Code Function Description Setting Range [Default]
d00.00 Controller series [Actual value]
Display controller series.
d00.01 Software version of DSP [Actual value]
Display software version of DSP.
d00.02 Special software version of DSP [Actual value]
Display special software version of DSP.
d00.03 Software version of the keypad [Actual value]
Display software version of the keypad.
d00.04 Elevator running status [Actual value]
Display the elevator running status in 16-bit binary, as shown in the following table:
Bit15: Battery driven run
0: No
1: Yes
Bit14: MS terminal 3
0: Invalid
1: Valid
Bit13: MS terminal 2
0: Invalid
1: Valid
Bit12: MS terminal 1
0: Invalid
1: Valid
Bit11: Down forced
speed switch input
0: Invalid
1: Valid
Bit10: Up forced speed
switch input
0: Invalid
1: Valid
Bit9: Contactor
feedback input
0: Invalid
1: Valid
Bit8: Brake feedback
input
0: Invalid
1: Valid
Bit7 - Bit4: Unused, marked as “0”
Bit3: Analogue run
0: No
1: Yes
Bit2: MS run
0: No
1: Yes
Bit1: Inspection run
0: No
1: Yes
Bit0: Controller enable
0: Disenable
1: Enable
123
d00.05 Rated current of HD3L [Actual value]
Display rated current of HD3L.
d00.06 Controller status [Actual value]
Display HD3L status in 16-bit binary, as shown in the following table:
Bit15: Unused Bit14: Unused
Bit13: Stop signal
0: No stop signal
1: Stop signal
Bit12: Contactor output
0: Invalid
1: Valid
Bit11: Brake output
0: Invalid
1: Valid
Bit10: Ready to run
0: Not ready
1: Ready
Bit9: Speed within FAR
0: No
1: Yes
Bit8: Auto-tuning
0: Not in auto-tuning
1: In auto-tuning
Bit7: Zero-speed
running
0: Invalid
1: Valid
Bit6: Zero-speed signal
0: Invalid
1: Valid
Bit5&Bit4: Acceleration / Deceleration / Constant
00: Constant
11: Unused
01: Acceleration
10: Deceleration
Bit3: DN
0: No
1: Yes
Bit2: UP
0: No
1: Yes
Bit1: Run / stop
0: Stop
1: Run
Bit0: Controller fault
0: No fault
1: Fault
\123
