Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3L Series Controller User Manual ―47―
Ref. Code Function Description Setting Range [Default]
F00.06 M-key function 0,1 [0]
0: Unused.
1: UP / DN switch. Switch the UP / DN of motor with key on the keypad.
F00.07 Speed setting of keypad 0.000 - F00.02 [1.500m/s]
F00.05 = 0, it sets the objective speed at running.
F00.08 Run direction 0,1 [0]
0: The same as run command.
1: Opposite to run command.
6.2.2 F01: Protection of Parameters
Ref. Code Function Description Setting Range [Default]
F01.00 User’s password 00000 - 65535 [0]
XXXXX: To enable the password protection function, set any non-zero number as the password.
• Once the password is set, and detect that there is no press on the keypad within 5 minutes, the user’s
password will be valid.
• To change the parameters, input correct password. Otherwise can not change any parameter via
keypad, but only check.
00000: The factory setting and no user’s password.
• If user unlocks the password, it means clearing the user’s password.
• To unlock, change and clear the user’s password, refer to section 5.2.3.
F01.01 Menu mode 0,1 [0]
0: Full menu mode. All parameters can be displayed.
1: Checking menu mode. Only parameters different from factory setting can be displayed.
F01.02 Function code parameter initialization 0 - 3 [0]
0: No operation. HD3L is in regular parameter read / write status.
• Whether can change the parameter depends on the user’s password status and the actual running
conditions of HD3L.
1: Restore to factory settings.
• Except Group F01, F07.00 - F07.14, F15.00, F17.11 - F17.27, Group F18 and Group Y.
• Steps: If set F01.02 = 1, press to ensure and the parameters are restored to factory settings. The
keypad dispalys “rESEt”. Then the keypad will display parameters in stop status after finish restoring to
factory setting.
2: Parameter download.
• Except Group F01, F17.11 - F17.27, Group F18 and Group Y.
• Motor parameters, encoder parameters and magnetic pole angle etc. will be downloaded.
• Record the original parameters such as motor parameters, encoder parameters and magnetic pole
angle etc. or restart parameter auto-tuning.
3: Clear fault information. The fault history of F17.11 - F17.27 will be cleared.
F01.03 Keypad EEPROM parameter initialization 0,1 [0]
0: No operation. HD3L is in regular parameter read / write status.
1: Upload the current function code settings to the keypad EEPROM parameter.
Note: Group F01, F17.11 - F17.27, Group F18 and Group Y do not upload.
