Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
―46― HD3L Series Controller User Manual
6.2 Group F: General Parameters
6.2.1 F00: Basic Parameters
Ref. Code Function Description Setting Range [Default]
F00.00 Motor type 0 [0]
0: Asynchronous motor.
F00.01 Motor control mode 0,1 [1]
0: V/f control. Constant voltage/frequency ratio control.
• It is applicable for special elevator occasion. This mode does not need the encoder and the control
effect is not so good as the vector control.
• When select V/f control, properly set the V/f control parameter of Group F07 to achieve proper
efficiency.
1: SVC control. Sensorless vector control.
Note:
Set motor parameter auto-tuning before selecting SVC control.
Auto-tuning steps: Correctly set the motor parameters (F07.00 - F07.04), then start the motor parameter
auto-tuning to obtain the right parameters. Meanwhile set vector control parameters of Group F08 to achieve
excellent vector control efficiency.
F00.02 Rated speed of elevator 0.100 - 4.000 [1.500m/s]
Refers to nominal rated speed of elevator.
• All of speed setting value in the parameters must < F00.02.
F00.03 Max. output frequency of HD3L 5.00 - 100.00 [50.00Hz]
Defines the max. frequency that HD3L is allowed to output.
• Be careful to set reasonable parameters according to the nameplate of the motor and the actual
operating conditions.
F00.04 Mechanical parameters of motor 10.0 - 6000.0 [60.0]
Defines the relationship between the elevator speed and the motor rotary speed.
• The mechanical parameters are calculated based on the motor parameters. They determine the control
precision and must be correctly set.
The relationship of elevator speed and rotary speed of motor is:
Elevator speed ms
⁄
Rotary speed of motor RPM
60
F00.04
1000
The formula for calculating F00.04 is:
F00.04
π D
i Winding mode
D: Diameter of motor (mm); i: Dec. rate; Winding mode: The way that the hoist cable is wound, set according to
the actual elevator setting.
F00.05 Operating mode 0 - 2 [0]
0: Keypad control.
• Controlled by pressing the or key of the keypad. Set the run speed in F00.07.
1: Terminal analogue control.
• The run command is controlled by UP and DN of the terminal, and the run speed is set by analogue
input terminals.
2: Terminal MS control.
• The run command is controlled by UP and DN of the terminal, and the run speed is set by MS1 - MS3
multi-step speed terminal combination.
