Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Troubleshooting and Maintenance
HD3L Series Controller User Manual 79
Fault Fault reasons Counter-measures
E0023
Faulty setting of
parameters
The power rating between motor
and controller is too different
Improper setting of motor
parameters
Select a controller with suitable power
rating
Set correct value of motor parameters
E0024
Fault of external
equipment
Fault terminal of external
equipment operates
Check external equipment
E0025
Too small running
current
Improper setting of F16.14, F16.15
Correct the setting of F16.14, F16.15
Check the connection between HD3L
and motor
Detect HD3L whether output
Detect whether the output contactor
work is nomal
E0028
SCI ommunication
timeout
Connection fault of
communication cable
Disconnected or not well
connected
Check the connection
E0029
SCI communication
error
Connection fault of
communication cable
Disconnected or not well
connected
Communication setting error
Communication data error
Check the connection
Check the connection
Correctly set the communication format
and the baud rate
Send the data according to MODBUS
protocol
E0032
Motor over speed
PG pulse number fault
Inadequate controller torque
Speed-loop PI parameter setting
is incorrect
Set proper PG pulse number
Select biger capacity controller
Correctly set speed-loop PI parameter
E0036
Contator fault
Contactor damaged
Feedback contact connection
problem
Change the contactor
Check the connection
E0037
Governor fault
Check external governor
Check feedback signal
Replace governor
Replace circuit
Note:
E0022 does not affect normal run of controller.
