HSD SM 141 D User Manual

A Technical characteristics
HSD S.p.A. © - h0124k00a.fm091115
59
ELECTRICAL AND MECHANICAL CHARACTERISTICS
Flash memory unit SM 141 - CPH 400
Dimension (x16 bits) K 32
Duration (writing/erasing) cycles 10000
Power output (3ph inverter) unit CPH 400
Inverter rated power W 507
Inverter rated current A
RMS
2,42
Leg rated voltage V
RMS
77,7
Rated frequency Hz 150
Overload max. voltage A 10
Overload duration s can be
parametrised
Commutation frequency kHz 10
Max. frequency Hz ND
OPERATING ENVIRONMENT unit SM 141 - CPH 400
Workplace temperature °C (°F) 5÷40 (41÷104)
Storage Temperature °C (°F) -25÷55 (-13÷131)
Transport temperature °C (°F) -25÷70 (-13÷158)
Workplace relative humidity (non-condensed)
@ 5÷40°C (41÷104°F)
%5÷85
Storage relative humidity (non-condensed)
@ -25÷55°C (-13÷131°F)
%5÷95
Transport relative humidity (non-condensed) @ 40°C (104°F) % 95
Maximum workplace altitude (unless otherwise agreed)
m
A.S.L.
2000
Storage maximum workplace altitude
Place to save above/below/ on sides mm 100/50/50
Expected short-circuits (nominal value) kA 1.5
Protective class I
Degree of pollution 2
Overvoltage category III
Power supply device*
*
Other settings than TN-S are not allowed (ex. IT, TT).
TN-S
Environment type: Second environment
Resistance to vibrations: 0,075 mm (10 ÷ 57 Hz) - 1 g (57 ÷ 150 Hz)
OPERATING ENVIRONMENT unit SM 141 CPH 400
Protection rating IP 54 65
