HSD SM 141 D User Manual

A Technical characteristics
60
HSD S.p.A. © - h0124k00a.fm091115
Protect and cut the power supply off by means of an automatic switch with cut-out
power of at least 1,5 kA (consistent with the max. expected short-circuits, declared
1,5 kA).
INTERFACE CONNECTIONS SM 141 - CPH 400
power electrical connection
1 INPUT: 7/8”
5-pole plug connector
SM141 450W electrical power connection
1 INPUT: M23
6-pole male connector
Fieldbus electrical (E-net) and logical power supply
P24V
1 INPUT: M12
5-pole plug connector
1 OUTPUT: M12
5-pole F-connector
Numeric inputs electric connection
4 INPUT: M8
3-pole F-connectors
MECHANICAL DATA Un. SM 141 CPH 400
Weight kg 3.5 ÷ 4.8 1.8 ÷ 2
Overall dimensions (L x H x P) mm
251* x 120.5 x 81
*
without shaft protrusion
238 x 120 x 81
Shaft protrusion mm 27 -
Output shaft diameter mm 14 -
CONTROL MODE unit SM 141
Feed-forward in position % 0:100
Speed control Interval rpm 100÷5000
Feed Forward in speed % 0:100
Torque control Interval A 0÷35.0
SM 141 - CPH 400 COMMUNICATION PROTOCOLS
E-NETx unit Values
Transmission speed Mbit/s 3
Max. distance from master (3Mbit/s) m 100
Number of addresses that can be selected n 32
Termination resistance
Fitted on the module and may be
selected through dip-switch
