HT EASYTEST COMBI519 User Manual

EASYTEST-COMBI519
EN - 38
6.5.3. Anomalous situations
1. If the instrument fails to generate the nominal voltage, it
emits a long acoustic signal to indicate the negative result
of the test and displays a screen like the one at the side.
M  15/10 – 18:04
R
Vt
T
=
=
=
0.01 M
0 V
3 s
NOT OK
MAN 500V
1.00M
L-PE
MODE Vtest Lim. FUNC
2.
A
t the end of the test, if the measured resistance value is
lower than the set limit, the instrument emits a long
acoustic signal to indicate the negative result of the test
and displays a screen like the one at the side.
M  15/10 – 18:04
R
Vt
T
=
=
=
0.29 M
534 V
3 s
NOT OK
MAN 500V
1.00M
L-PE
MODE Vtest Lim. FUNC
3. In AUTO mode, if the insulation measurement L-N is
<50k = 0.05M, all the tests are completed or if the
STOP key has been pressed, if RL-PE and RN-PE> Lim
and Vt> Vnom, the instrument shows a screen like the
one at the side. Disconnect the loads and resume the
test.
M  15/10 – 18:04
RL-N =
0.01M
Vt
=
15 V
RL-PE >
999 M
Vt = 525 V
RN-PE >
999 M
Vt = 524 V
Not OK – Check loads
AUTO 500V
1.00M
MODE Vtest Lim.
4.
A
t the end of the test, if the value of the test voltage is
lower than the nominal value, the instrument displays a
screen like the one at the side.
M  15/10 – 18:04
R
Vt
T
=
=
=
0.12 M
485 V
3 s
Vtest not correct
MAN 500V
1.00M
L-PE
MODE Vtest Lim. FUNC
