EASYTEST-COMBI519
EN - 21
6.1.1. Anomalous situations
1. If the instrument detects a L-N or L-PE voltage higher
than the maximum limit (265V), it does not carry out the
test and displays a screen like the one to the side. Check
the connection of measuring cables.
AUTO
15/10 – 18:04
TN
Isc=--- A ZL-N=--- Ω
Ifc=--- A ZL-PE=---Ω
Trcd=---ms Ircd=---mA
FREQ=50.00Hz Ut=---V
VL-PE=270V VL-N=272V
Voltage > 265V
30mA
500V
1.00M
In
Type Vtest Lim
2. If the instrument detects a L-N or L-PE voltage lower than
the minimum limit (100V), it does not carry out the test
and displays a screen like the one to the side. Check that
the system being tested is supplied.
AUTO
15/10 – 18:04
TN
Isc=--- A ZL-N=--- Ω
Ifc=--- A ZL-PE=---Ω
Trcd=---ms Ircd=---mA
FREQ=50.00Hz Ut=---V
VL-PE=15V VL-N=15V
Voltage < 100V
30mA
500V
1.00M
In
Type Vtest Lim
3. If the instrument detects that the phase and neutral leads
are inverted, it does not carry out the test and a screen
similar to the one reported to the side is displayed. Rotate
the mains plug or check the connection of the measuring
cables.
AUTO
15/10 – 18:04
TN
Isc=--- A ZL-N=--- Ω
Ifc=--- A ZL-PE=---Ω
Trcd=---ms Ircd=---mA
FREQ=--- Hz Ut=---V
VL-PE=--- V VL-N=--- V
Exchange L-N
30mA
500V
1.00M
In
Type Vtest Lim
4. If the instrument detects a dangerous voltage on PE
conductor, it does not carry out the test and displays a
screen like the one to the side.
AUTO
15/10 – 18:04
TN
Isc=--- A ZL-N=--- Ω
Ifc=--- A ZL-PE=---Ω
Trcd=---ms Ircd=---mA
FREQ=--- Hz Ut=---V
VL-PE=--- V VL-N=--- V
Voltage on PE
30mA
500V
1.00M
In
Type Vtest Lim
