HT EASYTEST COMBI519 User Manual

EASYTEST-COMBI519
EN - 60
6.
Press the GO/STOP key on the instrument, the START
key on the remote switch probe or use the AutoStart
feature (see § 5.1.5). The instrument starts the
measurement and the “Measuring…” message is shown
at display. During this whole stage, do not disconnect the
measuring leads of the instrument from the system under
test. The following screen appears on the instrument's
display.
LOOP 15/10 – 18:04
TN
max
psc
I
ZL-L
=
=
- - -
- - -
A

FREQ. = 50.00Hz
VL-PE=223V
VL-L=387V
Measuring…
L-L Br.Cap 15kA
FUNC MODE Lim
7.
In case of positive result (IpscMAX < Lim), the “OK”
outcome message is shown on the display.
LOOP 15/10 – 18:04
TN
max
psc
I
ZL-L
=
=
3019
0.16
A

FREQ. = 50.00Hz
VL-PE=223V
VL-L=387V
OK
L-L Br.Cap 6.0kA
FUNC MODE Lim
8.
In case of negative result (IpscMAX > Lim), the “NOT
OK” outcome message is shown on the display.
LOOP 15/10 – 18:04
TN
max
psc
I
ZL-L
=
=
7236
0.07
A

FREQ. = 50.00Hz
VL-PE=223V
VL-L=387V
NOT OK
L-L Br.Cap 6.0kA
FUNC MODE Lim
9. Press the SAVE key to store the test result in the instrument’s memory (see § 7.1) or
the ESC/MENU key to exit the screen without saving and go back to the main
measuring screen.
