5. If the instrument detects a dangerous voltage on PE
conductor, it provides the warning screen shown to the
side and blocks the execution of the tests. Check the PE
conductor and earth connection efficiency.
LOOP 15/10 – 18:04
TN
Ipfc
ZL-PE
=
=
- - -
- - -
A

FREQ. = 50.00Hz
VL-PE= 231V
VL-N= 234V
Voltage on PE
L-PE STD
FUNC MODE
6. If the instrument detects the absence of the signal to
terminal B4 (neutral conductor), it provides the warning
screen shown to the side and blocks the execution of the
tests.
LOOP 15/10 – 18:04
TN
Ipfc
ZL-PE
=
=
- - -
- - -
A

FREQ. = 50.00Hz
VL-PE= 231V
VL-N= 115V
Missing N
L-PE STD
FUNC MODE
7. If the instrument detects the absence of the signal to
terminal B3 (PE conductor), it provides the warning
screen shown to the side and blocks the execution of the
tests
LOOP 15/10 – 18:04
TN
Ipfc
ZL-PE
=
=
- - -
- - -
A

FREQ. = 50.00Hz
VL-PE= 115V
VL-N= 231V
Missing PE
L-PE STD
FUNC MODE
8. If the instrument detects the absence of the signal to
terminal B1 (phase conductor), it provides the warning
screen shown to the side and blocks the execution of the
tests
LOOP 15/10 – 18:04
TN
Ipfc
ZL-PE
=
=
- - -
- - -
A

FREQ. = 50.00Hz
VL-PE= 0V
VL-N= 0V
Missing L
L-PE STD
FUNC MODE
